> >>>>KDSHT30HTC200ES
New AHD-SHT30 View larger

KDSHT30HTC200ES

AHD-SHT30

New product

Product will be backorder, please contact us to specify the delivery date.

EGP 87.00

Data sheet

Video Output 4in1 - AHD/CVI/TVI/CVBS
Image Sensor 05- IMX323
Image resolution 02- 1080P / 960H
Effective Pixels 1920(H)*1080(V)
Focus Length 2.8-12mm
Focus Control Manual
Lens Type Manual
Pixels 3M Pixels
IR LED 14µ x 24PCS /￠5 (12µ) x 36PCS (Optional)
IR Distance 30M
White Balance AUTO / MANUAL
Gain Control AUTO
Noise Reduction 3DNR
Picture Adjustment Yes
WDR Yes
OSD Support Yes
UTC Yes
Housing IP66
Bracket Yes
IR Cut Filter Yes
Power Source 03- DC12V±10%, 700mA
Dimension 09-  ￠131 x 93(H) mm
Weight 800g
OSD Menu Language Yes
DSP 03- HTC1088
Electronic Shutter 1/25s~1/50,000s , 1/30s~1/60,000s
S/N Ratio ≥50dB
TV System PAL/NTSC
Scanning System Progressive Scan
Motor Iris Support NO
IR Status Under 10 Lux by CDS
IR Power On CDS Motor Control
Day/Night Yes
Dual Voltage No
Heater No
Operation Temperature -10℃ ~ +50℃ RH95% Max
Storage Temperature -20℃ ~ +60℃ RH95% Max
